| Input circuit |
8 circles |
| Input mode |
passive dry contact |
| busbar |
Half-duplex RS485 (Modbus RTU), three-wire shielded cable is recommended |
| Bus capacity |
≤8 |
| Switch event resolution |
The ability to distinguish between consecutive displacements of multiple contacts. If the displacement interval between any two contacts is greater than 1 millisecond, the ability to distinguish units (less than 2 ms) is reflected in the SOE. |
| Remote scanning speed |
The scan time of all channels for one week is 1 ms |
| Debounce time of the remote signal |
All channels use a uniform debounce time of 1 ms (configurable). |
| Power consumption |
≤5W |
| Power supply |
DC 24V, DC 100-350V, AC 85-265V |
| Installation |
DIN TS 35 mm |
